Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing
Negotiation
MOQ
USD 50-200/set
Price
Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: CHINA
Brand Name: BAOLIDA
Certification: ISO9001:2008
Model Number: BAOLIDA-09
High Light:

greenhouse cooling fans

,

fan pad cooling system

Payment & Shipping Terms
Packaging Details: STANDARD GREENHOUSE PACKAGE
Delivery Time: 7-10 DAYS
Payment Terms: MoneyGram, Western Union, T/T, D/P, D/A
Supply Ability: 30000 SETS A MONTH
Specifications
Product Name: Cooling System
Type: Cooling
Usage: For Agriculture
Application: Greenhouse
Color: Brown Green Black Red Blue
Height: 1500/1800/2000mm Or Customized
Thcikness: 100/150mm
Function: Plant Growing
Oem: Available
Shelf Life: 10 Years
Product Description

Agriculture Equipment For Greenhouse Cooling Pad System With Exhaust Fan


Company Information
Sichuan Baolida Mental Pipe Fittings manufacturing is a professional manufacturer and exporter of greenhouse &configurations. Our company is located in Chengdu Sichuan province , which is famous for "the city of tianfu" in China. Our main products comprise Tunnel Greenhouse, Glass Greenhouse, Polycarbonate Greenhouse, Plastic-film multi-span Greenhouse, and Solar greenhouse etc.
Moreover, We also have Greenhouse Materials, they can match all the kinds of greenhouse. Including greenhouse materials comparise Skeleton system, Aluminum-profile system, Covering system, Shading system, Ventilation system, Cooling system, Heating system, Seedbed system & Irrigation system, Hydroponic system.We also can design greenhouse according to your needs.The thing you should do is telling us the detail about your requirements and your country's weather.




Detail description



1. We can make the sizes according to your house size
2. Thickness: 100mm, 150mm, 200mm
3. Shade rate of greenhouse: 50%, 65%, 75%
4. Ventilation volume in greenhouse: 225/ 195/ 180m2/h
5. High efficiency used with exhaust fan,with principle of water evaporation,clear environment and low cost.
6. Made from hydroscopicity kraft paper, anti-corrosion, usable life, ripple height: 7mm or 5mm, ripple angle: 45*45.
7. long service life and good performance,popular used for greenhouse/poultry house/industrial workshop.





The system applies evaporation theory.

When the pump pumps water to the cooling pad, the hot air outside is pumped by the fan and passes the cooling pads at the same time; the water vaporizes from the pads and cools down the temperature in the greenhouse. The system consists of paper cooling pads, water circulation system ,exhaust fan and aluminum framework.
The lower humidity weather is, the better the effect of the cooling pads will be.
Wet pad was installed at one end of the greenhouse, the suction ventilator installed in the other end. When the air in greenhouse is needed to cool down, the control system of fan will start, the indoor air is forced out and build-up the negative pressure; At the same time, the water pump water the wet pad. The negative pressure cause the indraft through the wet pad , leading to evaporation and cooling, then the cold air flow through the greenhouse, absorb the indoor heat, so as to achieve the purpose of the circulating cooling.





Cooling pad parameter



H: high W: width D: depth H: wave height α: wave angle β: wave angle
Item 7090 7060 5090
H (mm) 1500 / 1800 / 2000 and so on 1500 / 1800 / 2000 and so on 1500 / 1800 / 2000 and so on
W (mm) 600 / 300 600 / 300 300 / 600 and so on
D (mm) 100 / 150 or as requirment 100 / 150 or as requirment 50 / 100 / 150 or as requirment
h (mm) 7 7 5
α (mm) 45 15 45
β (mm) 45 4

45







Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 0Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 1

Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 2
Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 3

Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 4Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 5Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 6


Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 7
Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 8

Greenhouse Evaporative Cooling System With Exhaust Fan Plant Growing 9

1. When can I get the price?
Usually within 24 hours after we get your inquiry. If you are urgent to get the price, please call me or tell me in the email.
2. Can you accept our own design, logo, and pattern?
We can produce it according to your design.
3. Are you a manufacturer or Trading company?
We are a greenhouse manufacturer in Chengdu China, are greenhouse manufacturing, and We also welcome you to visit our factory.
4. When can I get the goods?
Produce time is within 15days, and shipping is usually 20-35days.
5. What is your best price?
The same style of greenhouse can be used in different thicknesses of steel, and different thicknesses of the film. These will have a direct impact on greenhouse prices. And the larger the area, the lower the unit price will be
