High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project

Negotiation
MOQ
USD 2-6/sqm
Price
High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project
Features Gallery Product Description Request A Quote
Features
Specifications
Features: Strong Quality
Product Name: High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project
Width: 5m-12m
Usage: Agricultural Project
Covering: 100/120/150/200micro PE Film
Type: Single Span
Material: Hot Dip Galvanized Steel Pipe
Ventilation System: Side Ventilation With Insect Net
Production Time: 7 Days
Function: Structure Is Flexible, Strong Applicability And Wide Applicable Scope
High Light:

PE Film Single Span Greenhouse

,

10m Width Single Span Greenhouse

,

150 micron plastic tunnel greenhouse

Basic Infomation
Place of Origin: CHINA
Brand Name: BAOLIDA
Certification: ISO9001:2008
Model Number: BAOLIDA01
Payment & Shipping Terms
Packaging Details: Standard greenhosue package
Delivery Time: 7-14 WEEK DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500000 SQUARE METERS ONE MONTH
Product Description

High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project

Description



Single Span Greenhouse: The single-span greenhouse is a type of simple, safe and convenient universal greenhouse; it uses hot-dip galvanized steel pipes as the main framework, parts made under the hot-dip galvanized pressuring technique. The single-span greenhouse is mainly for vegetable and fruit cultivation and other aquaculture, besides its excellent insulation properties and necessary ventilation performance. We can also add sides manual rolling ventilation system to make it more practical.



Covering Material
1, 150 micro PE film.2, It has the advantage of strong tesion, good transmittance, anti-ultraviolet and so on.
3, Equipped with assembled accessories.



Main Frame
Hot Galvanized Steel Pipe
Covering Material
PE Film
Covering Material Lifetime
3-5 years
Column Shape
Rectangular/ round
Span
8m/9m/10m/12m
Width Between Columns
4m
Layer
1 layer
Top Height
3m-5m
Gutter Height
2.5m-6.5m
Wind Load
0.4KN/m²
Snow Load
0.3KN/m²

Film:

PE plastic single or double layer, different thickness according to the design. PE film has good properties of flow drop, weathering resistance, light transmittance and temperature preservation. It is a wide variety of agricultural film, which can be used not only in greenhouse but also on a large scale. Medium and small greenhouse, and energy-saving greenhouse early spring stubble cultivation is also more suitable.



Greenhouse Framework:



Our greenhouse is the simplest structure greenhouse with the lowest cost and the most convenient installation. The framework is the core structure of the tunnel greenhouse. It includes the groove, the door, the ridge, the arch, the end column and so on. The single-span greenhouse is usually in between 6m to 12m. Our product advantages are maximum use of the land area, simple installation, strong durability and long service life. Also, it is very convenient to disassemble for transport. So the cost will be the lowest and most cost-effective one



Product Application
Widely used for Low or High Single Tunnel Greenhouse and Multi Span Greenhouse, as protecting cover for fruit(strawberry, cherry, grape, watermelon, muskmelon and so on), vegetable(tomato, potato, eggplant, pepper, bean, cucumber, celery, onion and so on), flowers,poultry farming,edible mushrooms cultivation and so on.





High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 0

High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 1

High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 2



Packing and Delivery

1. The products are usually tied with packing tape.The packaging size and container capacity of the product are different from the product specifications
2. Container transportation, according to your project request. Production time usually costs 10-20 days.



High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 3High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 4

High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 5High Tunnel 150 Micron PE Film Single Span Greenhouse For Agricultural Project 6
