Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse

Basic Information
Place of Origin: Chengdu China
Brand Name: BLD
Certification: ISO9001:2008
Model Number: CD1-0.1
Minimum Order Quantity: 0
Packaging Details: The parts are packed in cartons, and the steel pipes are packed in conventional ways.
Delivery Time: 15 days
Payment Terms: Western Union, T/T
Supply Ability: 50000000sqm per month
Product Name: Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse Produce Time: Within 15days
Shipping Method: By Sea Technicsl: Hot-dip Galvanized Steel Pipe
MOQ: NO MOQ Width: 8m A Span
Top Height: Standard 2.8m (accept Customized) Shoulder Height: Standard 1.5m (accept Customized)
Length: Accept Customized Application: Plants Cultivation
High Light:

Aluminized Zinc Single Span Greenhouse

,

PF Film Single Span Greenhouse

,

Single Span Tunnel Plastic Greenhouse

Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse



Description

The front part is covered by PC board, the structure is more solid; All sides are covered with plastic film. High-tunnel shape, suitable for tall plants. Both sides of the ventilation system with insect net, is conducive to ventilation in the greenhouse, insect net can prevent diseases and insects.



Structure introduce

The greenhouse uses a tunnel structure, with the Arch on either side sinking 30-50 cm underground. The 30 cm underground depth ensures the stability of the greenhouse, and the input is not high. Both sides of the greenhouse are equipped with manual ventilation devices, which can effectively ensure air circulation. In the ventilation area on both sides, there is also an internal insect-proof net, which can prevent the entry of harmful insects and organisms.



Covering Material

The covering material of greenhouse is polyethylene droplet film, which has good light transmittance, good insulation, good droplet resistance, good weather resistance, long service life and other excellent characteristics. And effectively block ultraviolet light, reduce ultraviolet light through the shed. Our standard sizes are 80 microns and 150 microns thick.



Main Features


1) Simple and strong structure, easy to install and maintain
2) The greenhouse is used to protect from the rain, preserve moisture, insect prevention,cool, keep warm and so on.
3) Excellent hot galvanized steel structures and accessories, anti-corrosion, 15-year using life
4) Ventilation and insect nets can give your planting under the comfortable situation. Increasing yield
5) Best after-sales service and 15years of experience in greenhouse



Parameter

Item Details
Material Hot Dipped Galvanized Steel
Features Simple structure and economic type
Structure is flexible, strong applicability and wide applicable scope
High quality Lock Channel and Hot-dip Galvanization
Width 8m/9m/10m or Customized (8m is standard)
Length 30m-60m or Customized
Shoulder Height 1.5m-1.8m or Customized
Roof Height 3.5m or Customized
Wind Load 0.4KN/M2
Snow Load 0.35KN/M2
Max Rain Quantity 140mm/h


Examples of pictures

Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 0Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 1Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 2Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 3



Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 4Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 5

Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 6Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 7

Polycarbonate PC Board Greenhouse High Tunnel Plastic Film Side Ventilation Single-Span Greenhouse 8

Our services

1. Reliable design: a strong and creative design, research and development team to design the greenhouse according to the local climate and geographical conditions.

2. Greenhouse installation: engineers can be sent to your country for greenhouse installation.

3. Quality assurance: we have strict quality control and mature technology, our products have achieved

National and industry standards.All our exports will be strictly inspected before shipment.

4. One-to-one 24-hour online service: for any questions, please contact us.

5. After-sales service: if there is any quality problem during the warranty period, we will assume the responsibility and provide on-site service as needed.
