Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato

USD3-6/sqm
Price
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato
Features Gallery Product Description Request A Quote
Features
Specifications
Products Name: Strawberry Growing Tunnel Greenhouse
Shipping Way: By Sea
Technicsl: Aluminum Plated Zinc Steel Tube
MOQ: NO MOQ
Top Height: Standard 2.8m (accept Customized)
Wall Height: Standard 1.5m (accept Customized)
Country Of Origin: China
Brand: Baolida
High Light:

Tunnel Single Span Greenhouse

,

Heat Preservation Single Span Greenhouse

,

150mic Tunnel Plastic Greenhouse

Basic Infomation
Place of Origin: Chengdu China
Brand Name: BLD
Certification: ISO9001:2008
Model Number: CD1-0
Payment & Shipping Terms
Packaging Details: The parts are packed in cartons, and the steel pipes are packed in conventional ways.
Delivery Time: 15 days
Payment Terms: Western Union, T/T
Supply Ability: 50000000sqm per month
Product Description

               Agriculture Poly Tunnel Green Steel Frame House

Single Span Tunnel Greenhouse Heat Preservation Quilt Winter Plastic Film Tomato Passive Greenhouse

Description
This greenhouse is suitable for growing all kinds of plants. Cash crops such as peppers, kale, cucumbers, watermelons, strawberries and tomatoes are ideal. Such a greenhouse is economically comfortable, not only flexible structure and wide range of applications. It has an efficient rainwater drainage system. Strong wind resistance. The whole is made of high quality steel hot dip galvanized processing. Fully custom designed and high quality materials. Therefore, it is popular in many countries and regions in the world. Not only that, it can also be used with a variety of auxiliary systems, irrigation system, hydroponic system, lighting system, seedbed system, etc.

Structure introduce
Tunnel structure. The overall frame structure of the greenhouse consists of two arch sections on the left and right, each of which is inserted 30-50 cm underground. This structure ensures the stability of the greenhouse structure. Artificial ventilation is adopted on both sides of the greenhouse to ensure air circulation when the greenhouse is opened. The ventilation area is set with a 40-mesh insect net to prevent harmful insects and organisms from entering the greenhouse, protect the safety of crops and ensure the normal production of crops. If due to breeding, the requirements are higher, but the basic design is the same, the skeleton material size and thickness are relatively large, covering materials are generally covered with blankets and other thermal insulation materials. There are two kinds of ventilation: natural ventilation and forced ventilation. Forced ventilation needs to be equipped with a cooling system.

Covering Material
The influence period of PE dripless film flow is generally 2 ~ 4 months. Using non-ionic surfactant, no drop film has excellent anti-fogging performance, shelf life can reach 1 ~ 5 years, and anti-aging ability basic synchronization. Greenhouse film is made of polyethylene drip - free film. The material not only has good light transmittance, good heat preservation performance, good droplet resistance, good weather resistance and other excellent characteristics, but also long service life. This material can effectively block ultraviolet rays, greatly extending the life of the entire greenhouse. Our standard thickness films are 80 micron, 150 micron and 200 micron thick. We can also provide other types of film, you can choose the type and thickness of the film you want, you are sure to be able to choose the covering material to your satisfaction.

Parameter

Item Parameter Remark
Product model CD1-0

Ventilation system and shading system can be added.

Standard size W 8m, L 10m-60m Accept Customized
Wall height 1.5 meters Accept Customized
Arch φ25mm*1.5mm Can be changed
wall column φ25mm*1.5mm Can be changed
Covering material 80 / 150 micron Can be changed


Examples of pictures
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 0Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 1Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 2Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 3

Transportation
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 4

Production
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 5

Certificate
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 6

Customer visit and praise
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 7
Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 8

Service
1. We can design the most suitable greenhouse for you according to your local climate and your needs.
2. We will give you a detailed quotation, so that you can clearly see the composition of the price.
3. We provide a 5-year warranty service for steel pipes and a 3-year warranty service for covering materials.
4. we have a professional construction design team, can give you the production of detailed construction drawings, at the same time to give you remote technical guidance.
5. We also cooperate with many agricultural factories to help you with one-stop shopping.

Plastic Film Tunnel Single Span Greenhouse Heat Preservation For Winter Tomato 9


FAQ
1. When can I get the price?
Usually within 24 hours after we get your inquiry. If you are urgent to get the price, please call me or tell me in the email.
2. Can you accept our own design, logo and pattern?
We can produce it according to your design.
3. Are you manufacturer or Trading company?
We are greenhouse manufacturer in ChengDu China,We are greenhouse manufacturing, and We also welcome you to visit our factory.
4. When can I got the goods?
Produce time is within 15days, and shipping is usually 20-35days.
5. What is your best price?
The same style of greenhouse can be used in different thickness of steel, and different thickness of film. These will have a direct impact on greenhouse prices. And the larger the area, the lower the unit price will be
