Description
Tunnel greenhouse is the cheapest One of the most affordable forms of greenhouse, which aimed at reducing its infrastructure directly inserted into the underground, in some cold area, they can be heat insulation ACTS as a canopy, edible fungus can grow vegetables, flowers, such as greenhouse apply to almost any crop varieties, especially suitable for cucumber Watermelon ordinary agricultural economic crops, such as pepper, such as Chinese cabbage Strawberry tomato and so on main material for high quality galvanized steel sheet, we will according to the actual situation for you to customize your area So our greenhouse in many countries and regions in the world are very popular In addition, the greenhouse can also lighting system with a hydroponic system such as agricultural irrigation systems seedbed system auxiliary system, to improve the efficiency of agricultural production.
Structure introduce
The design of the tunnel not only ensures the stability of the greenhouse structure, but also will not increase the cost of artificial ventilation in the greenhouse design. In order to make the air circulation in the greenhouse, the ventilation area is set up with 40 mesh insect control net side ventilation, which can prevent pests from entering the greenhouse and ensure the safety of crops If used for animal husbandry production, greenhouse frame requirements are higher, in the case of maintaining the same structure, only the size of the basic frame material and reinforcing steel thickness, in order to keep warm, the outermost layer of the greenhouse needs to increase cotton as insulation material, to prevent heat loss.
Covering Material
PE used non-ionic surfactant technology, plastic film with excellent anti-fog performance generally, the shelf life of material is usually 1-5 years, its anti-aging ability and polyethylene basic same, has the good permeability light good insulation characteristics of leakage prevention Good weathering resistance and a series of excellent performance 150 our standard film thickness is 80 microns Micron and 200 micron In addition, we can also provide other types of materials and thickness, is sure to meet your needs.
Parameter
| Item | Parameter | Remark |
| Product model | CD1-0 |
Ventilation system and shading system can be added. |
| Standard size | W 8m, L 10m-60m | Accept Customized |
| Wall height | 1.5 meters | Accept Customized |
| Arch | φ25mm*1.5mm | Can be changed |
| wall column | φ25mm*1.5mm | Can be changed |
| Covering material | 80 / 150 micron | Can be changed |
Examples of pictures
Transportation
Production
Certificate
Customer visit and praise
Service
1. We can design the most suitable greenhouse for you according to your local climate and your needs.
2. We will give you a detailed quotation, so that you can clearly see the composition of the price.
3. We provide a 5-year warranty service for steel pipes and a 3-year warranty service for covering materials.
4. we have a professional construction design team, can give you the production of detailed construction drawings, at the same time to give you remote technical guidance.
Contact us
FQA
1. When can I get the price?
Usually within 24 hours after we get your inquiry. If you are urgent to get the price, please call me or tell me in the email.
2. Can you accept our own design, logo and pattern?
We can produce it according to your design.
3. Are you manufacturer or Trading company?
We are greenhouse manufacturer in ChengDu China,We are greenhouse manufacturing, and We also welcome you to visit our factory.
4. When can I got the goods?
Produce time is within 15days, and shipping is usually 20-35days.
5. What is your best price?
It is depends.
