Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato
Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Chengdu China
Brand Name: BLD
Certification: ISO9001:2008
Model Number: BLD-TP-913
High Light:

4m High Tunnel Plastic Greenhouse

,

Tomato Single Span Tunnel Plastic Greenhouse

,

200micro PE Film Single Span Greenhouse

Payment & Shipping Terms
Packaging Details: The parts are packed in cartons, and the steel pipes are packed in conventional ways.
Delivery Time: 15 days
Payment Terms: Western Union, T/T
Supply Ability: 50000000sqm per month
Specifications
Produce Name: Single-span Greenhouses
Shipping Method: By Sea
Structure: Hot Galvanized Steel Frame
Width Of Greenhouse: 8-10m A Span
Shoulder Height: Customized
Length: 10-100m, Customized
Application: Plants Cultivation
Covering: 150/200micro PE Film
Optional System: Cooling System, Irrigation System,heater,lights
Product Description

Commercial Plastic Agricultural Greenhouse Single Span High Tunnel Tomato Single-Span Greenhouses

Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 0

The Single-span greenhouse is widely used in the cultivation of tomatoes, vegetables, fruits, and flowers. It can provide the conditions of suitable illumination, moisture, and temperature, raising the output and resisting natural disasters. It can bring forward or backward the provision, remitting the contradictions of provision and demand.

it is composed of hot galvanized pipe with three layers of film for the covering material. The frame structure is simple, cheap cost and easy to install.



The structure we use hot-dip galvanized pipe to avoid rust.
· Frame of hot-dip galvanized steel pipe.
· Span of 6.4/8/9.6/10 meters is available.
· Total structure height - 4.3 meters to 6.5 meters.
· Covering material thickness - 0.15mm or 0.12mm.
· Good at keeping warm.
· Arch roof.
· May only be covered by polyethylene held with aluminum clips.
· Suitable for all climate conditions and adaptable to any type of landscape.



Can add below systems:(Depend on customers' request)

● Cooling and heating system

● Irrigation system

● Ventilation system

● Fertilization system

● Shading system

● Benches





Parameter



Greenhouse Frame

Hot galvanized steel pipe,diameter is 25mm,32mm,40mm,42mm,50mm,60mm

Cover film

PE 120micron,150micon,200micron,customize

Length

10-100m,customize

Width

6m,7m,8m,9m,10m, can customize

Roof height

3-6m, can customize

Wall height

2-4m, can customize

Ventilation

Two sides ventilation by manual/electric roll-up machine

Wind load

80-130km/h

Snow load

0.5KN/M2

Plants hanging load:

0.15KN/m2

Rain drainage

140mm3/h

Option Item

Cooling fan,cooling pad,shade net,heater,lights,irrigation system

Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 1Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 2Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 3

Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 4



Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 5Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 6

Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 7Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 8Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 9

Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 10Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 11



Commercial Agricultural High Tunnel Plastic Greenhouse Single Span for Tomato 12

1. When can I get the price?
Usually within 24 hours after we get your inquiry. If you are urgent to get the price, please call me or tell me in the email.
2. Can you accept our own design, logo, and pattern?
We can produce it according to your design.
3. Are you a manufacturer or Trading company?
We are a greenhouse manufacturer in Chengdu China, are greenhouse manufacturing, and We also welcome you to visit our factory.
4. When can I get the goods?
Produce time is within 15days, and shipping is usually 20-35days.
5. What is your best price?
The same style of greenhouse can be used in different thicknesses of steel, and different thicknesses of the film. These will have a direct impact on greenhouse prices. And the larger the area, the lower the unit price will be
